The DV65 Entro-V is a highly efficient, top entry MVHR unit that can recover over 85% of the wasted heat.

The unit is reliably manufactured to ensure high thermal efficiencies with optional ancillaries such as electric heaters, F7 (ISO ePM1 60%) supply air filter and various sensors. The DV65 has low energy EC fans that minimise the unit's energy consumption therefore can help reducing energy bills.

The unit has an easy to maintain plastic counterflow heat exchanger that prevents the airstreams from mixing and easy to clean air filters that provide you with a clean, healthy indoor air environment.

The DV65 Entro-V complies with the ErP 2016 standards and also conforms with the more stringent proposed ErP 2018 Directive. The unit comes with an outstanding 2-year warranty and is SAP Appendix Q eligible.

Includes an easily removable, plastic heat exchanger which transfers warmth from the outgoing waste airstream into the incoming fresh air with thermal efficiency over 85%. At no point do the airstreams mix.

The DV65 Entro-V unit is designed with a double filter facility that comes with 2 x G4 (ISO ePM Coarse 55%) filters as standard. There is the option to have a F7 (ISO ePM1 60%) pollen filter included, which provides additional protection against invisible, harmful particles and creates an ultra hygienic environment, particularly relevant for those suffering from asthma or other respiratory conditions.


The Entro-V ventilation units with heat recovery are available for a large variety of building sizes. The smallest unit size in the range, Entro-V DV65, can supply up to 242 m3/h (67.2 l/s) and can be installed in vertical mounting positions, on the wall or on the floor. Hanging brackets, screws, and feet are supplied with the unit. Also, the unit has interchangeability of spigots position from top to the sides. In addition to high-quality individual ventilation components, an overall integrated concept is essential to a well-functioning ventilation system. Airflow offers the ideal ventilation system solutions and guarantees easy design, safe installations, and maximum efficiency.

Supply and extract air to and from rooms is done through antistatic smooth bore, hygienically lined AirflexPro ducting. Ensuring minimal in-duct airflow noise and dirt accumulation, it is supplied economically straight from the roll. The durable, ribbed outer skin of AirflexPro offers excellent flexibility, strength and compressibility, up to 10 kN / m2. These properties make it ideally suited for embedding straight into concrete screed without distortion, which ensures predicted airflow rates through ducts are maintained.

AIRFLEXPRO - MOVING AIR EFFICIENTLY AND EFFECTIVELY. AirflexPro is an air ducting system, when used in conjunction with a Mechanical Heat Recovery Unit (MVHR) it provides a total ventilation system for dwellings. AirflexPro is a radial ducting system offering advantages over the more traditional branch systems. AirflexPro is suited to a new build but can also be used in the retrofit market and can be combined with such technologies as Coanda valves. The system has zero leakage and low system pressure, therefore making it a very efficient air movement system.



KEY FEATURES:
• For use in dwellings up to 116m2
• Over 85% thermal efficiency capabilities
• "A+" energy rating
• Two controller options (basic or digital). Basic is supplied with this kit.
• Double G4 (ISO ePM Coarse 55%) filter design with an optional F7 (ISO ePM1 60%) supply air filter - ISO 16890 compliant
• Automatic, 100% summer by-pass
• Compact design with a vertical mounting position
• Durable galvanised steel casing, powder paint coated line with 20mm EPP (expanded polypropylene) insulation
• Choice of spigot locations (top entry as standard)
• Complies with Building Regulations
• SAP Appendix Q eligible
• 2-year warranty



Dimensions:
L580 x D430 x H690mm

Please see the below brochure for more information including a full list of kit contents.
